Tags: braga


Buyer Rates (0/5):
  • Ex Tax:R6,443.00
  • Brands Braga
  • Product Code: S-LBMW9088DK
  • Availability: In Stock

Available Options

BRAGA Optimal series car stereo for BMW F30/F31/F32/F33 2013 - 2017 is a premium quality head unit that does not go beyond a high budget. This car radio offers you not to chase super high performance, but to get premium quality equipment, the speed of which is more than sufficient for most needs in the car. Buying a radio for the BMW 3 SERIES F# Optimal series is a profitable investment, as well as the acquisition of excellent functionality in the car.

Key features
Brand / Manufacturer:BRAGA
Operation system:Android 13 R
Display:10.25/12.3 inches IPS (2.5D)
Resolution:HD 1920х720 px
Processor:1.5 GHz Quad-core (Allwinner T5)
Memory:2 Gb LPDDR2
Built-in storage:32 GB/64GB
Apple CarPlay / Android Auto:Built-in

BRAGA BMW F30/F31 Android Car Stereo Navigation In-Dash Head Unit has a lot of advantages as opposite to the original car multimedia system. OS Google Android 11 R based car stereo is much more functional than other operating systems car devices. Everything that is available in your modern smartphone or a tablet now it is easy to access in BRAGA multimedia system. Everything what you need is at arm's length! The bright 9 inches IPS (2.5D) screen is visible everywhere at sunny weather. There are excellent HI-FI soundpremium qualityhigh performance, multitasking, easy to use, unique simple interface and much more! Modern components and optimized software make  BRAGA Audi BMW 3 SERIES F30 a leader among premium automotive head units!

BRAGA Android 13 R Car Navigation Head Unit for Audi A4 / S4 / RS4 runs on the high-performance platform with 1.5 GHz Quad-core (Allwinner T5) processorIncreasing the number of cores improves performance and allow to make the device much faster. Reaction to the user signals is instantaneous and without any "freezes". Diagonal screen is 10.25/12.3 inches IPS (2.5D) with HD 1920x720 px LCD resolution, display brightness is very high and it will be seeable even at sunny day. When car lights are switched on, the screen brightness automatically becomes darkfield, also the brightness function can be tuned in a manual way and enables to customize the screen with individual preferences. Capacitive touchscreen technology allow to control all functions easy and safely while car driving.


Special features:

  • 10.25/12.3 inches IPS (2.5D), capacitive multi-touch screen;
  • HD 1920x720 px LCD resolution;
  • Android 13 R;
  • 1.5 GHz Quad-core (Allwinner T5) processor;
  • 2 Gb LPDDR2 RAM;
  • 32 Gb/64GB, expansible through SD card;
  • GPS / Glonass positioning system, external antenna is included;
  • FM / AM radio with RDS and memory for 36 radio stations, high sensitivity NXP TEF6686 FM module;
  • Hi-Fi sound processor, 4 x 50W sound amplifier MOSFET TDA 7850 class AB ;
  • Equalizer: Bass / Middle / Treble, Loud. Cutoff frequency: BassF / MiddleF / TrebleF. Separate volume control for loud speaker (subwoofer);
  • On-board WI-FI, Hotspot mode (access point for other Wi-Fi devices);
  • 3G / 4G Internet is supported through an external USB modem (isn't included);
  • Bluetooth HandsFree. Phonebook copy function and phonebook search. Separate volume control. A2DP music playback;
  • TMPS (tire-monitoring pressure system) and OBD2 adapters, connection through Bluetooth;
  • Steering wheel buttons, supporting 3 programmable functions for one button (short / long / repeat press);
  • RGB front panel buttons backlight, every color can be adjusted;
  • Faceplate buttons function can be changed, 3 programmable functions for one button (the same as steering wheel buttons);
  • Backup camera, supporting every rear cameras (some models support original factory cameras, dynamic lines and park assistance system);
  • Front parking camera supporting through the "FCAM" or "AUX Video In" port connection;
  • Standby Mode (10, 30, 60 minutes), the unit will be switched on for 1 second;
  • Android cold boot time for 20-25 seconds;
  • Supporting of USB Flash, SD Card (up to 64 Gb) and hard drives (up to 1 Tb);
  • Supported video formats: RMVB, MKV, MOV, WMV, AVI, MPG, TS with 1080P, H.264, etc.;
  • Supported audio formats: MP3, WMA, WAV, OGG, FLAC, etc.;
  • Support Full HD 1080p video playback;
  • Video output - RCA Female (NTSC, PAL);
  • External amplifier supporting, 4 channel (Left / Right Front + Left / Right Rear), RCA Female connectors;
  • External loud speaker (subwoofer) supporting, RCA Female connector, separated sound level in the EQ settings;
  • Dynamically changing the volume depends on the vehicle speed, 3 modes: low / medium / strong;
  • Navigation voice prompts. You can choose speakers for voice navigation: front or all;
  • Microphones, there are two kinds: on-board and external. You can use handsfree function and Android voice programs (Google Voice search, Skype, voice control, etc.);
  • Video inputs: 1 x rear view camera (RCA Female connection), 1 x AUX In (RCA Female connection), some models have 1 x Front CAM input (RCA Female connection);
  • AUX Audio input, some models support factory AUX input;
  • USB / SD card port, 2 x USB ports, some models support factory USB;
  • Set up your car logo or custom logo;
  • Warranty 12 months.


Package includes:

  • BRAGA Car Stereo Head Unit for BMW f30/F31/F32/F34;
  • Main power cable for BMW 3 Series;
  • CAN-bus module (if applicable);
  • USB 3G-modem and USB Flash Drive connection cables;
  • Audio / Video connection cables;
  • FM antenna connection adapter (if applicable);
  • Adapters for original USB and AUX ports (if applicable);
  • GPS / Glonass antenna;
  • External microphone(Optional);
  • Wi-Fi antenna;

Remark: the manufacturer reserves the right to change the packaging, specifications and design without prior notice, but functionality and quality of the product can not be deteriorated

>>>Support Steering wheel control

Remain iDrive Knob system

You can switch volume and apps display too

>>>Car Information Displaying

Support car information displaying

Such as: Oil fuel, Speed, Temperature....

>>>Support Rear View Camera

Support car factory 360 camera parking sensors displaying.

Also support AHD camera input.

Note: It can only support ISUDAR AHD camera.

>>>Support USB DVR

Connect with USB port, display on radio screen,

Record driving status, instant playback


Octa Core Cortex A53, Upto 2.0GHz


>>>IPS HD Screen

Resolution: 1920*720P, Full view angle

More Clearer, More Brighter

>>>Built-in Bluetooth

Support Bluetooth handfree

Support Bluetooth music playback

>>>Built in Carplay&android auto

Then it would have android auto and wirelss carplay both function too, no need to buy extra dongle.

Easy to use phone app in the big head unit screen.

>>>Built-in GPS & Glonass

With IGO map and could suppport sygic ,waze and so on.

Also support On-line maps, real-time traffic information displaying
